4.7 Jeep Stroker Engine with Edelbrock Aluminum Head

5.00 out of 5
(1 customer review)

INCLUDES:

  • 4.0 Jeep Stroker engine assembly.
  • Peak Horsepower:  285bhp @ 5200rpm Peak Torque:  320lb/ft @ 4000rpm
  • Compression Ratio:  9.3 :1
  • Operating Range:  Idle – 5200rpm
  • Recommended Fuel:  91+ Octane Pump Gasoline
  • Block Specifications:  Jeep 4.0 Cast Iron Block
  • Crankshaft –  Scat  Cast Steel 3.895″ Stroke / 2.125 Snout .850 Pilot Hole
  • Block Decked  -Bored .030-.040”
  • Internally Balanced Front and Rear – Performance Torque Plate Honed
  • New Durabond Cam Bearings Installed Rods:
  • Main Caps Line Honed
  • Connecting Rods  with ARP Bolts
  • Speed Pro Hypereutectic Pistons with Anti-Friction Coatings
  • Chrome Moly Piston Rings
  • Bearings:  – Clevite / Enginetech  Main & Rod Bearings clearance checked
  • Comp Cams or Equiv Hydraulic Flat Tappet
  • 12 Hydraulic Lifters
  • Timing Set: – Cloyes Single Roller
  • Oil Delivery: Melling  Performance Standard Volume Oil pump
  • Melling Oil Screen Pickup
  • Fel Pro Permaseal Head Gaskets .040”
  • Edelbrock Alumimum Cylinder Head
  • Bolt down Harland Sharp Roller Pedestal Rockers
  • Comp Cams Pushrods
  • Full Gasket Set
  • * Valve cover,  Oil pan , Timing Cover Add – $289.00





$6,699.00

Availability: In Stock
- +
Compare

TD Motion Offers

4.7 Jeep Stroker Engine with Edelbrock Aluminum Head

Are you sick of not having enough power to climb those hills? Did those larger tires you installed suck the life out of your stock 4.0L engine? The TD MOTION  4.7L Jeep Stroker Engine with its 270hp and 300 ft lbs of torque will bring life back to your Jeep. Thus make it enjoyable to drive again!! Add more  Fun to your factory Jeep 6 cylinder with this 4.7 Stroker Assembly. Long block Includes a lot upgrades over the factory engine.
MAIN SPECS:

  • Peak Horsepower:  290bhp @ 5200rpm Peak Torque:  320lb/ft @ 4000rpm
  • Compression Ratio:  9:1
  • Operating Range:  Idle – 5200rpm
The facts you need to know about the 4.7L Jeep Stroker Engine:
  • Will pass emissions in most 50 states when tuned in a proper way
  • Works fine with all automatic and STD transmissions
  • Works in place of a 4.0 Factory Engine

PRODUCT COMPATIBILITY:

1987-2004 Jeep 4.0

Year Range Make Model
1987-2001 Jeep Wrangler
1989-1993 Jeep Cherokee

INCLUDES:

  • 4.0 Jeep Stroker engine assembly.
  • Peak Horsepower:  285bhp @ 5200rpm Peak Torque:  320lb/ft @ 4000rpm
  • Compression Ratio:  9.3 :1
  • Operating Range:  Idle – 5200rpm
  • Recommended Fuel:  91+ Octane Pump Gasoline
  • Block Specifications:  Jeep 4.0 Cast Iron Block
  • Crankshaft –  Scat  Cast Steel 3.895″ Stroke / 2.125 Snout .850 Pilot Hole
  • Block Decked  -Bored .030-.040”
  • Internally Balanced Front and Rear – Performance Torque Plate Honed
  • New Durabond Cam Bearings Installed Rods:
  • Main Caps Line Honed
  • Connecting Rods  with ARP Bolts
  • Speed Pro Hypereutectic Pistons with Anti-Friction Coatings
  • Chrome Moly Piston Rings
  • Bearings:  – Clevite / Enginetech  Main & Rod Bearings clearance checked
  • Comp Cams or Equiv Hydraulic Flat Tappet
  • 12 Hydraulic Lifters
  • Timing Set: – Cloyes Single Roller
  • Oil Delivery: Melling  Performance Standard Volume Oil pump
  • Melling Oil Screen Pickup
  • Fel Pro Permaseal Head Gaskets .040”
  • Edelbrock Alumimum Cylinder Head
  • Bolt down Harland Sharp Roller Pedestal Rockers
  • Comp Cams Pushrods
  • Full Gasket Set
  • * Valve cover,  Oil pan , Timing Cover Add – $289.00

BENEFITS:

  • Lighter Weight with Aluminum Head
  • Increased Torque and Horsepower
  • Runs on Pump GAS

Weight 500.0000 lbs
